The standard retention levels available are 0, 1, 3, 4.
We also provide gel-sticky carrier with tray and empty boxes (see below)

  • low tack level (0, 1) for polished surfaces
  • medium tack level (3) for etched surfaces
  • high tack level (4) for rough surfaces



TYPE: HP1-5510A
Inside Dimension: 51mm x 51mm x 7mm
                                   (2" x 2" x 0.276")
Outside Dimension: 55mm x 55mm x 10mm
                                      (2.17" x 2.17" x 0.39" )
Colour: Transparent/Black
Height of cover/bottom: 5mm/5mm
                                          (0.197"/0.197")
Retention Grade: 0, 1, 3, 4










TYPE: HP1-5510B
Inside Dimension: 51mm x 51mm x 7mm
                                  (2" x 2" x 0.276")
Outside Dimension: 55mm x 55mm x 10mm
                                       (2.17" x 2.17" x 0.39" )
Colour: Transparent/Black
Height of cover/bottom: 3.5mm/6.5mm
                                           (0.138"/0.256")
Retention Grade: 0, 1, 3, 4













TYPE: HP1-7515
Inside Dimension: 72mm x 51mm x 12mm
                                   (2.84" x 2" x 0.473")
Outside Dimension: 75mm x 55mm x 15mm
                                     (2.95" x 2.17" x 0.59")
Colour: Transparent/Black
Height of cover/bottom: 7.5mm/7.5mm
                                            (0.3" / 0.3")
Retention Grade: 0, 1, 3, 4













TYPE: HP1-8512A
Inside Dimension: 81mm x 81mm x 8.5mm
                                 (3.19" x 3.19" x 0.33")
Outside Dimension: 85mm x 85mm x 12mm
                                     (3.35" x 3.35 " x 0.472")
Colour: Transparent/Black
Height of cover/bottom: 6mm/6mm
                                          (0.236" x 0.236")
Retention Grade: 0, 1, 3, 4











TYPE: HP1-12012A
Inside Dimension: 118mm x 118mm x 10mm
                                  (4.65" x  4.65" x 0.39")
Outside Dimension: 120mm x 120mm x 13.5mm
                                      (4.73" x 4.73" x 0.53")
Colour: Transparent/Black
Height of cover/bottom: 5mm/8.5mm
                                           (0.197"/0.335")
Retention Grade: 0, 1, 3, 4











TYPE: HP1-24018
Inside Dimension: 235mm x 115mm x 13mm
                                   (9.26" x 4.53" x 0.51")
Outside Dimension: 240mm x 120mm x 18mm
                                      (9.46" x 4.73" x 0.71")
Colour: Transparent/Black
Height of cover/bottom: 9mm/9mm
                                           (0.35"/0.35")
Retention Grade: 0, 1, 3, 4

 You can also choose different carrier dimensions from the Empty Boxes shown below for your applications
New: Vacuum Gel box

HP1-Vacuum


Vacuum gelpak

Inside Dimension: 51mm x 51mm x 7mm
                                   (2" x 2" x 0.276")
Outside Dimension: 55mm x 55mm x 10mm
                                      (2.17" x 2.17" x 0.39" )
Colour: Black/Black
 Retention Grade: 1, 3



TYPE: HP2-5510 Tray
Tray Dimension: 51mm x 51mm x 4mm  (2" x 2" x 0.158")
Colour: Transparent/Black
Retention Grade: Low
Use with 5510A empty box		 TYPE: HP2-8512 Tray
Tray Dimension: 80mm x 80mm x 6mm  (3.15" x 3.15" x 0.236" )
Colour: Transparent/black
Retention Grade: Low
Use with 8512A empty box
(unit in mm)  ESD safe!

#
Overall size
Net size
Body colour
L
W
H
L
W
H
HP-5510A
55
55
10
51
51
7
Trans./Trans.
HP-5510B
55
55
10
51
51
7
Trans./Trans.
HP-5520
55
55
20
51
51
16.5
Trans./Black
HP-7515
75
55
15
72
51
12
Trans./Black
HP-8512
83
83
12
81
81
8.5
Trans./Trans.
HP-8526
83
83
26
81
81
23
Other Colour
can be
customized
HP-12012
120
120
13.5
118
118
10
HP-13060
130
60
36
127
57
33
HP-24018
240
120
18
235
115
13
Trans./Trans.
HP-24025
240
120
25
235
115
20
Trans./Trans.
